Gauge block stack

Target height → minimal combination from a standard gauge block set per DIN 861 / ISO 3650.

Select gauge block set

112-piece set (comprehensive) 112 Blöcke · 1,0005 · 1,001–1,009 · 1,01–1,49 · 0,5–24,5 (0,5) · 25–100 (25) 103-piece set 103 Blöcke · 1,005 · 1,01–1,49 · 0,5–24,5 (0,5) · 25–100 (25) 87-piece set 87 blocks · 1,001–1,009 · 1,01–1,49 · 0,5–9,5 (0,5) · 10–100 (10) 56-piece set (standard) 56 blocks · 1,0005 · 1,001–1,009 · 1,01–1,09 · 1,1–1,9 · 1–24 · 25–100 (25) 47-piece set (basic) 47 Blöcke · 1,005 · 1,01–1,20 (0,01) · 1,3–1,9 (0,1) · 1–9 · 10–100 (10) 8-piece (25–200 mm) 8 blocks · long gauge blocks without fine increments - only whole support dimensions. 8-piece (125–500 mm) 8 blocks · long gauge blocks for large workpieces.

Target height [mm]

Die Stapelhöhe fürs Sinuslineal rechnet Messen → Sinuslineal aus Länge und Soll-Winkel. Vier Nachkommastellen von dort abtippen ist die häufigste Fehlerquelle - der Link übernimmt sie.
